High Precision Transient Waveform Recorder with Energy Harvesting CT

Products can be customised

The High Precision Transient Waveform Recorder is an integrated device designed for power line monitoring and transient waveform recording applications. It combines a protective enclosure, an energy harvesting current transformer (CT), and a waveform recording module in one compact unit.Featuring a PC and glass fiber housing, a 304 stainless steel spring structure, and an IP68 protection rating under specified test conditions, the device is designed for demanding electrical

Operating temperature :
-40℃~75℃
Certification :
CE, UL
Frequency :
50～60Hz
Fire resistance property :
UL94-Vo
Output Power :
1A / 5mW
Inner diameter :
60mm

Inquiry now

Product Details

Working principle

High-Precision Waveform Recorder Enclosure is designed for power line monitoring and electrical measurement applications. It features a durable PC and glass fiber housing, a 304 stainless steel spring structure, and an integrated power harvesting current transformer.

The product is designed to provide mechanical protection, reliable cable clamping, and auxiliary power supply for compatible monitoring equipment. Its IP68 protection rating and wide operating temperature range make it suitable for demanding outdoor electrical environments, subject to the specified installation conditions.

Application

Self-Powered Power Line Monitoring Equipment

Overhead power line monitoring

Power line fault monitoring systems

Electrical waveform recording equipment

Distribution network monitoring

Remote electrical measurement systems

Compatible self-powered monitoring devices

Key Features

- Integrated Power Harvesting CT: Supports auxiliary power generation for compatible monitoring devices.

- High Measurement Accuracy: Sampling accuracy of less than ±0.5% when tested with the specified circuit board.

- IP68 Protection: Tested at a water depth of 1.5 meters for 36 hours under the specified test conditions.

- Flame-Retardant Housing: PC and glass fiber material with UL 94 V-0 rating, subject to material certification.

- Durable Clamping Structure: 304 stainless steel spring designed for secure cable installation.

- Wide Operating Temperature: Suitable for operating environments from -40°C to +75°C.

- Mechanical Durability: Designed to withstand the specified drop-impact and cable-retention tests.

High Precision Transient Waveform Recorder

Electrical Parameter	Typical Current Sampling Accuracy	<±0.5%
	Power Output Test Condition	3 A input current, 400 Ω load Output Voltage Greater than 3.3 V under the specified test condition
	Ingress Protection	IP68; 1.5 m water depth for 36 hours
	Flame Retardant Rating	UL94-V0
	Operating Temperature	-40~75 ℃
	Relative Humidity	<95%RH
	Maximum Operating Altitude	<4000 Meter


5. Customization and Technical Support

We can evaluate product suitability according to your application requirements, installation dimensions, conductor specifications, output power requirements, and operating environment.

Please provide your target application, cable dimensions, minimum operating current, required output voltage, and power consumption. Our team can help confirm the appropriate configuration for your project.

6. Inquiry Information

For technical evaluation and quotation, please share your application details, required quantity, installation conditions, and any available drawings or technical specifications.
